An init system in a Docker container

DockerHere’s another quick post about docker, sorry again if it will come out a bit raw.

In my previous post I talked about my first experiments with docker. There was a number of unanswered questions at first, which got an answer through updates to the blog post during the following days. All but one. When talking about a containerized process that needs to log through syslog to an external server, the post concluded:

if the dockerized process itself needs to communicate with a syslog service “on board”, this may not be enough…

Continue reading

A dockerized policy hub

DockerThis is a quick post, apologies in advance if it will come out a bit raw.

I’ve been reading about docker for a while and even attended the day of docker in Oslo. I decided it was about time to try something myself to get a better understanding of the technology and if it could be something useful for my use cases.

As always, I despise the “hello world” style examples so I leaned immediately towards something closer to a real case: how hard would it be to make CFEngine’s policy hub a docker service? After all it’s just one process (cf-serverd) with all its data (the files in /var/cfengine/masterfiles) which looks like a perfect fit, at least for a realistic test. I went through the relevant parts of the documentation (see “References” below) and I’d say that it pretty much worked and, where it didn’t, I got an understanding of why and how that should be fixed.

Oh, by the way, a run of docker search cfengine will tell you that I’m not the only one to have played with this 😉

Continue reading

The future of configuration management – mini talks

On March 7th I was at the DevOps Norway meetup where both Jan Ivar Beddari and me presented an extended version of the ignite talks we held at Config Management Camp in February. The talks were streamed and recorded through Hangouts and the recording is available on YouTube.

The meeting gave me the opportunity to explain in a bit more detail my viewpoint about why we need a completely new design for our configuration management tools. I had tried already in a blog post that caused some amount of controversy and it was good to get a second chance.

I’d recommend you watch both Jan Ivar’s talk and mine, but if you’re interested only in my part then you can check out here:

And don’t forget to check out the slides, both Jan Ivar’s and mine.

Managing system services with CFEngine

An important system service is not running...

I have experienced that when people talk about a system’s configuration, they mostly think of software to be installed and configuration files to be deployed. That’s true, they are part of a system configuration, but there’s more to it — if Configuration Management was only that, you could rightfully call it “provisioning” instead. For example, another part of a system’s configuration is that certain critical services must be running and/or certain other services must not be running. And in fact, any configuration management tool has provisions to manage system services and ensure they are in the desired state (while they may differ a lot on the “when” and “how” and “how often” the state is checked).

CFEngine is no exception. You can take advantage of ready-to-use frameworks like NCF or EFL, or  roll your own checks. What I’m presenting you today is a simple bundle that I wrote called watch_service, that you can use to ensure that certain system services are up or down.

My approach is similar to NCF’s bundle called service_action in that it tries to provide a generic, system-agnostic bundle to manage services but with a few differences:

  • while service_action relies on information in NCF itself to make the bundle simpler to use, my watch_service relies only on CFEngine’s standard_services knowledge as available in the standard library;
  • while service_action returns information to the agent in the form of namespace-scoped classes (e.g.: the service was in the desired state, or the service was not in the desired state and the problem has been fixed successfully), watch_service only reports about the events by means of another bundle called report, whose code will be also provided in the last part of this post.
  • service_action supports many different actions, watch_service only supports “up” (ensure the service is running) or “down” (ensure the service is not running).

Continue reading

Rudimentary compliance report for CFEngine

In CFEngine community you don’t have a web GUI with compliance report. You can get them via EvolveThinking’s Delta Reporting, but if you can’t for any reason, you need to find another way.

A poor man’s compliance report at the bundle level can be extracted via the verbose output. This is how I’ve used it to ensure that a clean-up change in the policies didn’t alter the overall behavior:

cf-agent -Kv 2>&1 | perl -lne 'm{verbose: (/.+): Aggregate compliance .+ = (\d+\.\d%)} && print "$1 ($2)"'

These are the first ten lines of output on my workstation:

bronto@brabham:~$ sudo cf-agent -Kv 2>&1 | perl -lne 'm{verbose: (/.+): Aggregate compliance .+ = (\d+\.\d%)} && print "$1 ($2)"' | head -n 10
/default/banner (100.0%)
/default/inventory_control (100.0%)
/default/inventory_autorun/methods/'proc'/default/cfe_autorun_inventory_proc (100.0%)
/default/inventory_autorun/methods/'fstab'/default/cfe_autorun_inventory_fstab (100.0%)
/default/inventory_autorun/methods/'mtab'/default/cfe_autorun_inventory_mtab (100.0%)
/default/inventory_autorun/methods/'dmidecode'/default/cfe_autorun_inventory_dmidecode (100.0%)
/default/inventory_autorun (100.0%)
/default/inventory_linux (100.0%)
/default/inventory_lsb (100.0%)
/default/services_autorun (100.0%)

Not much, but better than nothing and a starting point anyway. There is much more information in the verbose log that you can extract with something slightly more elaborated than this one-liner. Happy data mining, enjoy!

Bug or feature? Dereferencing of arrays and namespaces

CFEngineAgentNow that the upgrade from 3.4 to 3.6 is advancing slowly but steadily I am starting to check the features that are new in 3.6 compared to 3.4.  According to the docs namespaces were actually introduced in 3.4.0, but I didn’t take advantage of them yet, and it’s time to start.

When something is declared in a namespace (a bundle, a variable or whatnot) it must be referred to with its namespace. For example, if you declare a bundle test in the namespace nstest, you’ll refer to that bundle from outside the namespace (e.g. in the bundlesequence) as nstest:test. If you declare a variable, for example an array called conf in that bundle, that will be nstest:test.conf outside the namespace. So far so good.

Now, what happens inside the namespace? Well, I found one fact that is indeed surprising.

Continue reading

hENC now on github

github-logo hENC is a radically simple external node classificator for CFEngine that I developed as part of my work in Opera starting from 2013. To my surprise and despite its simplicity, it was so much appreciated by the community that I was encouraged to present it at FOSDEM and Configuration Management Camp in 2014, which I did with much to my satisfaction.

This year I presented an updated version of the same talk at the Software conference in Oslo and I was asked if the code was open source and available. It wasn’t yet, and the main reason was that I knew it would take an effort to generalize it, to abstract it from our environment and make it suitable to be used anywhere. And it did: if you look at the history it took 16 days and 24 commits before I was happy enough with the result to publish it. But I finally did and it’s now available on githubNow it’s your turn.

You can do a lot to help these contribution coming. Give them a chance. If they seem to solve your problem, try them; if they actually help you, contribute to them if you have a chance; if you don’t have a chance to contribute you can at least promote them.

The CFEngine community is rather small and doesn’t have the large ecosystem of tools that other CM communities can boast about. Despite that, pearls like EvolveThinking’s EFL, Delta Reporting and Delta Hardening or Normation’s NCF (to name only a very few!) are there: help them grow, help more tools come, support developers to keep up the good work, share and encourage sharing, contribute back if you can. More than anything else, please let’s stop reinventing the wheel every time and become good at sharing.

If you do, everybody wins: you win because you get more tools, and we win because we see that our contributions are useful and appreciated.

Thanks in advance
-- bronto
